| Parameter | Specification Details |
|---|---|
| Model | ECI-M001 |
| Process type | Rotary die plastic cup thermoforming |
| Action object | plastic PP PET |
| Scope of application | Disposable plastic cup |
| Mold material |
|
| Number of cavity | 8 |
Allows for simultaneous processing of multiple clothing molds on a single machine, significantly reducing production time and boosting overall efficiency.
By enabling multiple molds to be formed on the same machine, it helps save valuable space on the production line, making it ideal for compact manufacturing environments.
Designed for large-scale production, the mold supports an "eight-out-of-one-cavity" configuration, enabling rapid completion of large quantities in a short timeframe.
Constructed from premium materials such as 45# alloy steel, aluminum alloy, and tool steel, ensuring exceptional wear resistance and thermal conductivity.
Flip die thermoforming technology is widely utilized in the production of lunch boxes and tableware, offering versatile application scenarios across various industries:
Ideal for manufacturing lunch boxes used in restaurants, fast-food chains, and takeout services in various shapes like square, round, and rectangular.
Suitable for food processing companies to create robust packaging containers, takeout boxes, and pastry packaging products.
Meets high demands for retail-ready lunch boxes, ensuring they are aesthetically pleasing, functional, and fully compliant with health standards.
Customize the turnover mold based on the specific shape and structural requirements of the target product.
Gather the necessary raw plastic sheets (such as PP or PET) according to product specifications.
Load the plastic sheet into the thermoforming machine and heat it until it reaches a highly pliable state.
Attach the softened sheet to one side of the mold, then flip the mold to shape the plastic against the cavity.
Allow the shaped plastic to cool down within the flipped mold to maintain its structural form.
Open the mold carefully once the product has fully solidified and remove the formed lunch box.
Perform finishing operations including deburring, trimming, and cleaning off excess material.
The ECI-M001 mold is designed specifically for rotary die plastic cup thermoforming, primarily targeting the production of disposable plastic cups.
The action objects for this mold are PP (Polypropylene) and PET (Polyethylene Terephthalate) plastic materials.
The mold body uses forged and tempered 45# steel, the edges are made of Cr12MOV, the stretch head is nylon, and the cup cavity is constructed from high-quality aluminum alloy.
It features an 8-cavity (eight-out-of-one-cavity) configuration, which enables high-volume manufacturing of finished products in a short timeframe.
This technology is widely used in the food service industry, food packaging manufacturing, and retail sectors for producing lunch boxes, tableware, and takeout containers.
